TranslateToF/Thermal PMOD
PMOD_Thermal32
The PMOD_Thermal32 module is a low-cost thermal imaging module compliant with the PMOD interface standard. It can be directly inserted into the PMOD slot of the MaixCAM Pro and combined with a visible light camera to achieve dual-light fusion functionality.
| Module Name | PMOD_Thermal32 |
|---|---|
| Resolution | 32x24 |
| Temperature Range | -40°C to 450°C |
| Field of View (FOV) | 55° x 35° |
| Frame Rate | 1~30fps |
| Interface | I2C |
PMOD_Thermal32 Installation Guide
Thermal Imaging with Pseudo-color Display
Thermal Imaging + Visible Light Fusion Display
Reference Code:
GitHub Repository
PMOD_TOF100
The PMOD_TOF100 module is a low-cost array ToF module compliant with the PMOD interface standard. It can be directly inserted into the PMOD slot of the MaixCAM Pro and combined with a visible light camera to achieve dual-light fusion functionality.
| Module Name | PMOD_TOF100 |
|---|---|
| Resolution | 100x100, 50x50, 25x25 |
| Measuring Range | 0.2~2.5m |
| Field of View (FOV) | 70°H x 60°V |
| Laser Emitter | 940nm VCSEL |
| Frame Rate | 100x100: 6fps, 50x50: 22fps, 25x25: 30fps |
| Interface | SPI |
PMOD_TOF100 Installation Guide
Depth Imaging with Pseudo-color Display
Depth + Visible Light Fusion Display
Reference Code:
GitHub Repository
